NCN15-30GM40-Z1
The NCN15-30GM40-Z1 (089272) is a high-performance sensor engineered to detect metal objects reliably in industrial environments. With a 15 mm sensing range and a 30 mm cylindrical body, it delivers consistent performance and easy installation. Its contactless design reduces wear for long-term stability.
Equipped with a 2-wire DC, normally closed (N.C.) output and a 2 m PVC cable, it integrates smoothly into automation systems, providing flexible and durable operation for industrial applications.
