NBB2-V3-E3
NBB2-V3-E3
The NBB2-V3-E3 (087721) is a compact and reliable surface mount inductive proximity sensor designed for accurate metal detection in industrial automation systems. With a 2 mm sensing range, it ensures precise detection even in tight spaces, making it ideal for assembly lines and automated machinery.
This sensor features a 3-wire DC, PNP, normally closed (N.C.) output and comes with a 130 mm PVC cable, providing easy integration into existing control systems. Its contactless operation reduces mechanical wear, delivering consistent performance and long-lasting reliability for production lines and industrial equipment.
Description
Key Features
- Accurate metal detection with a 2 mm sensing distance
- Compact surface mount design for limited spaces
- 3-wire DC, PNP, N.C. output for easy system integration
- Contact-free operation minimizes wear and maintenance
- PVC cable, 130 mm, for flexible connectivity
- Durable performance in demanding industrial settings
Typical Applications
- Automation and machine control
- Metal component detection in tight spaces
- Conveyor and material handling systems
- Robotics and automated equipment
- General industrial automation tasks
Technical Specifications
- Product Name: NBB2-V3-E3
- Part Number: 087721
- Sensor Type: Inductive Proximity Sensor
- Mounting Style: Surface Mount
- Sensing Distance: 2 mm
- Output Type: 3-wire DC, PNP, N.C.
- Connection: PVC cable, 130 mm
- Weight: 57.4 g
