ICS TRIPLEX T8403 Trusted TMR 24 Vdc Digital Input Module
ICS TRIPLEX T8403 Trusted TMR 24 Vdc Digital Input Module
Technical Specifications
General
Manufacturer: ICS Triplex
Part Number: T8310
Product Type: Trusted TMR Digital Input Module
System: Trusted™ TMR
Electrical
Input Voltage: 24 Vdc
Number of Inputs: 40 channels
Input Measurement: Sigma-Delta (Σ-Δ) circuit
Isolation Rating: 2500 V optical/electrical
Diagnostics & Monitoring
Line Monitoring: Configurable per channel
Fault Detection: Open circuit and short circuit detection
SOE Resolution: 1 ms
Status Indication: Channel LEDs and module status LED
Maintenance & Operation
Hot Swap Support: Companion Slot and SmartSlot
Operating Modes: Active, Standby, Educated
Application Areas: Safety systems, process control, industrial automation
Description
The ICS TRIPLEX T8310 Trusted TMR Digital Input Module is a high-reliability, 40-channel 24 Vdc digital input module designed for safety-critical industrial control systems. Built on a Triple Modular Redundancy (TMR) architecture, the T8310 delivers exceptional fault tolerance and dependable signal processing in demanding operational environments.
Each input channel is independently protected using TMR design and a Sigma-Delta (Σ-Δ) input circuit, ensuring accurate voltage measurement and continuous system validation. Integrated diagnostics and automated self-testing enable early fault detection while maintaining uninterrupted system operation. The module supports per-channel line monitoring, allowing precise identification of open circuits and short circuits in field wiring.
For event analysis and troubleshooting, the T8310 includes an onboard Sequence of Events (SOE) function with 1 ms resolution, using configurable voltage thresholds to detect state changes. High-level 2500 V optical/electrical isolation ensures compliance with safety isolation requirements. Designed for operational flexibility, the module supports online hot replacement via Companion Slot or SmartSlot configurations. Front-panel LEDs clearly display input status, wiring faults, and module health, making maintenance faster and safer.
Key Features
Trusted™ TMR digital input module for safety-related systems
40 digital input channels with 24 Vdc operation
Triple Modular Redundancy per channel for fault tolerance
Σ-Δ input circuits for accurate voltage measurement
Comprehensive onboard diagnostics and self-tests
Independent line monitoring per channel (open/short detection)
Onboard SOE reporting with 1 ms resolution
2500 V pulse-withstand optical/electrical isolation
Supports hot replacement via Companion Slot or SmartSlot
Front-panel LEDs for input status, wiring faults, and module health
