NBB15-U4-A2-V1
NBB15-U4-A2-V1
The NBB15-U4-A2-V1 (203023) is engineered for consistent metal detection in industrial automation systems. Its 15 mm sensing distance enables precise, non-contact switching, helping reduce mechanical stress and improve equipment longevity.
Designed with a 4-wire DC PNP output, it accommodates both Normally Open and Normally Closed functions for easy PLC compatibility. The M12 x 1, 4-pin connection ensures fast installation and a secure fit. Optimized for round-the-clock use, this sensor maintains dependable performance even in challenging operating conditions.
Description
Key Features
- Consistent and accurate metal detection
- 15 mm sensing distance ideal for limit switch functions
- 4-wire DC PNP output for flexible system integration
- Supports both N.O. and N.C. output modes
- Standard M12 x 1, 4-pin connector for easy installation
- Built to withstand long-term industrial use
Built for Tough Industrial Conditions
The NBB15-U4-A2-V1 is made to perform in real-world industrial environments where dust, vibration, and nonstop operation are common. The ability to use both N.O. and N.C. outputs reduces the need for multiple sensor types, helping simplify system design and spare management. It’s a dependable solution for applications where accuracy, uptime, and durability are essential.
Typical Applications
- Limit switch and position detection
- Machine tool automation
- Assembly and packaging lines
- Industrial control and monitoring systems
Technical Overview
Product Name: NBB15-U4-A2-V1
Part Number: 203023
Sensor Type: Inductive Proximity Sensor
Body Style: Limit Switch
Sensing Distance: 15 mm
Output Type: 4-wire DC, PNP, Normally Open & Normally Closed
Connection: M12 x 1, 4-pin
