The IS200STTCH2A is a DIN rail-mounted thermocouple terminal board developed for seamless integration into GE Mark VIe control system architectures. This terminal board plays a critical role in interfacing thermocouple sensors with the control system, offering accurate temperature measurement essential for turbine operation, power generation, and other high-reliability industrial environments.

Designed specifically for turbine environments, the IS200STTCH2A is compatible with a wide range of thermocouple types including Type E, J, K, N, S, and T. The board supports 12 thermocouple inputs, each with built-in cold junction compensation (CJC), ensuring reliable temperature readings under varying environmental conditions. This feature is particularly important in gas and steam turbine applications, where thermal accuracy and fast response are essential to performance and safety.

The board is mounted via DIN rail, allowing for simple installation in control panels and ensuring a clean, compact footprint within the overall system design. Each thermocouple channel is isolated and protected, which minimizes signal interference and provides enhanced system safety. The signal path between the IS200STTCH2A and the I/O processor (typically the PAICH module) is facilitated by a plug-and-play terminal block connector, supporting rapid deployment and serviceability.

Built to meet rigorous industrial standards, the IS200STTCH2A has been engineered for use in harsh operating environments, with temperature-tolerant components and robust terminal connections that reduce the risk of failure due to vibration, dust, or humidity. The terminal board is typically used in conjunction with the Mark VIe’s analog input pack, where it plays a vital role in ensuring that process data from temperature sensors is digitized and processed with minimal delay or distortion.

The IS200STTCH2A enhances plant reliability by enabling real-time monitoring of turbine temperatures, which is critical for detecting overheating, thermal imbalance, or degradation in performance. Its compact form, industrial-grade design, and compatibility with GE’s high-performance Mark VIe platform make it a trusted solution for OEMs and field engineers worldwide.

This thermocouple board is a vital part of the temperature sensing infrastructure in any Mark VIe deployment, supporting accurate, stable, and noise-free signal transmission across the system.

Key Features:

• Supports up to 12 thermocouple inputs with CJC

• Compatible with thermocouple types E, J, K, N, S, T

• DIN rail mountable for compact, efficient installation

• Designed for GE Mark VIe turbine control systems

• Isolated channels for noise-free, safe operation

• High accuracy signal transmission and thermal compensation

• Built for harsh industrial conditions with rugged design

• Plug-and-play connectivity with PAICH or I/O processors
