CJ15+U1+A2
CJ15+U1+A2
The CJ15+U1+A2 (CJ15-U1-A2 / 001604) is a reliable limit switch built for accurate position and end-of-travel detection in industrial automation. With a 15 mm operating distance, it provides precise and consistent switching to support safe and efficient machine operation.
Designed for everyday industrial use, it features a 4-wire DC PNP output with both N.O. and N.C. contacts, making integration simple across different control systems. The screw terminal connection allows quick, secure wiring and easy maintenance. Its durable construction ensures long-lasting performance in demanding environments.
Description
Key Features
- 15 mm operating distance for accurate position detection
- Limit switch design for reliable end-of-travel and safety control
- 4-wire DC PNP output with N.O. and N.C. options
- Screw terminal connection for secure and easy wiring
- Durable construction for long-term industrial use
- Stable and repeatable switching performance
Typical Applications
- Machine position and limit detection
- End-of-travel monitoring in automation systems
- Packaging and assembly machinery
- Material handling equipment
- General industrial control and safety systems
Technical Specifications
- Product Name: CJ15+U1+A2
- Model Number: CJ15-U1-A2
- Part Number: 001604
- Device Type: Limit Switch
- Operating Distance: 15 mm
- Operating Voltage: DC
- Output Type: 4-wire, PNP, Normally Open and Normally Closed
- Connection: Screw Terminal
