Allen Bradley 1756-IH16I: A High-Performance Digital Input Module
Allen Bradley 1756-IH16I: A High-Performance Digital Input Module
Model: 1756-IH16I
Brand: Allen Bradley
Number of channels: 16
Input voltage range: 90-146 VDC
Isolation voltage: 250 VDC
Cyclic update rate: 200 µs – 750 ms
Input impedance: 48.67 kΩ @ 146 VDC
Change of state detection: Software configurable
Time stamp of inputs: ±200 µs
Module keying: Electronic, software configurable
Removable terminal block housing: 1756-TBCH or 1756-TBS6H
Weight: 0.5 lbs. (0.23 kg)
Dimensions: 4.72 x 2.95 x 2.25 in. (12 x 7.5 x 5.7 cm)
Description
The Allen Bradley 1756-IH16I is a high-quality digital input module designed for use with the ControlLogix family of programmable logic controllers (PLCs). Engineered for high accuracy and reliability, this 16-channel isolated input module provides robust performance in demanding industrial automation environments.
Each input on the 1756-IH16I is individually isolated, helping to reduce electrical noise and interference while enhancing system safety. This makes the module ideal for connecting to a wide variety of field devices such as sensors, switches, and relays. It supports a flexible range of input voltages, allowing for use in applications that require both standard and custom signal types.
The module integrates easily into ControlLogix systems, making it a dependable choice for expanding or upgrading existing automation setups. It also features built-in diagnostics, providing real-time input status and simplifying troubleshooting. These capabilities help reduce system downtime and improve overall operational efficiency.
Built for harsh environments, the 1756-IH16I is constructed with industrial-grade materials to ensure long-term durability and reliable performance, even under extreme conditions. Whether in manufacturing, process control, or machine automation, this module offers the precision and stability required for critical input signal monitoring.
Applications include factory automation, material handling, process monitoring, and equipment control—anywhere accurate digital signal acquisition is essential.
Now available in original packaging and ready for quick shipping, the Allen Bradley 1756-IH16I is a trusted solution for enhancing digital input capabilities in modern automation systems.
