The Allen Bradley 1746-HSCE High-Speed Counter Module is a compact, high-performance solution designed to meet the demanding needs of industrial automation systems. Known for its reliability, precision, and versatility, this module is an essential component for accurate counting and measurement applications.

Key Features of the 1746-HSCE Module

• High-Speed Counting Capabilities: Supports counting frequencies up to 1 MHz, ensuring precise data capture for fast-moving processes.

• Multiple Input Options: Offers 4 differential or 8 single-ended input channels for enhanced signal compatibility.

• Flexible Counting Modes: Easily configure for various counting tasks, including up/down, quadrature, and rate measurement.

• Advanced Filtering: Integrated noise filtering improves signal integrity and measurement accuracy.

• Customizable Output Signals: Configurable outputs allow seamless integration with PLCs and other industrial devices.

• User-Friendly Interface: Simplifies configuration and diagnostics, reducing setup time.

• Compact Design: Space-saving form factor (118mm x 35mm x 87mm) fits into tight control panels with ease.

Common Applications

The 1746-HSCE module is ideal for applications requiring high-speed and high-accuracy counting, including:

• Conveyor Systems

• Batch Processing and Mixing Lines

• Position and Motion Control

• Packaging and Labeling Machines

• Precision Event Tracking

Industry Use Cases

The 1746-HSCE module is widely used across industries such as:

• Manufacturing – for machine control and throughput optimization

• Automotive – in assembly lines for position tracking

• Pharmaceutical – for accurate batching and dosing control

• Food and Beverage – for high-speed packaging and labeling

Technical Specifications

• Input Voltage: 5V DC

• Input Channels: 4 differential or 8 single-ended

• Maximum Count Frequency: 1 MHz

• Update Time: 0.1 ms

• Module Dimensions: 118mm (H) x 35mm (W) x 87mm (D)

Benefits of the 1746-HSCE High-Speed Counter

• Exceptional Accuracy: Ensures reliable performance even in high-speed environments

• Versatile Signal Compatibility: Supports a wide range of input types

• Seamless Integration: Easily connects with other Allen Bradley SLC 500 systems and third-party automation devices

• Space-Efficient Design: Ideal for control panels with limited space

• Boosts Productivity: Enables faster response times and optimized process control

Conclusion

The Allen Bradley 1746-HSCE High-Speed Counter Module is a trusted choice for professionals seeking reliable, accurate, and high-performance counting solutions in industrial automation. Its flexible configuration options, compact design, and robust feature set make it suitable for a wide range of industries and applications.

Enhance your automation system’s performance with the 1746-HSCE module – a smart investment for improving efficiency, accuracy, and overall productivity.
